The perfect laser light show starter kit! This package bundle includes our incredibly popular RAW 1.7 laser system, FB3QS control hardware, and QuickShow software. Providing you with everything you need to start creating incredible laser shows.
Videos
Laser projector
FB3QS and QuickShow
Mains cable
Inbuilt Control Signal cable
E-STOP with inbuilt XLR cable
E-STOP with inbuilt XLR cable
Safety keys
USB drive with manual
QC certificate
Quality certificate
BEYOND License
Learn more
Rain Cover
Learn more
DiscoScan 2.0 Lens
Learn more
DiscoScan 2.0 Lens Bracket
Learn more
Product Name: | Unity RAW 1.7 (DMX+ILDA) |
Type Of Laser: | Full-colour, Semiconductor diode laser system |
Guaranteed Optical Output: | >1.8W |
Suitable For: | Clubs, DJs, smaller indoor venues, home and hobby use. Beam show, text, graphic, and mapping capable |
Control Signal: | DMX mode, sound active mode, and ILDA mode (we recommend Pangolin FB3QS and QuickShow for ILDA control) |
Scanning System: | 35,000 points per second @ 8° |
Scan Angle: | 50° |
Safety: | Fully complies with the latest EN 60825-1 and FDA regulations |
Weight: | 5.3kg |
Package Includes: | Power cord, 10M ILDA signal cable, E-STOP box with 10M cable, Set of 4 safety keys, 3-pin interlock bypass plug, User guide. |
R | G | B [mW]: | 350 | 500 | 1000 |
Beam Size [mm]: | 5 x 3 |
Beam Divergence: | <1.1mrad [Full Angle] |
Modulation: | Analog 50kHz |
Power Requirements: | 100-230V/50Hz |
Consumption: | Max. 100W |
Operation Temperature: | 10-40 °C |
Ingress Rating: | IP4X |
System Features: | Adjustments for color channels (R,G,B), size/position/invert (X,Y), DMX in/out, ILDA in/out, Estop in/out, power in/out, sound active mode, digital display for DMX address and settings |
Laser Safety Features: | Keyed interlock, Emission delay, Magnetic interlock, Scan-fail safety, Mechanical shutter, Adjustable aperture masking plate. |
Notice: | *Due to Advanced Optical Correction technology used in our laser systems, each laser color's optical power output may slightly differ from the specification of the respective laser module(s) installed. This does not affect the total guaranteed power output. |
Dimensions [mm]: |
Depth: 238 Width: 192 Height: 126 |
