About the
RAW FB4
The RAW FB4 series is a high impact, low cost laser system that provide you with the same control setup as the industry's leading laser companies, all within an affordably priced laser package. The RAW FB4 series is offered in powers ranging from 3W to 10W, covering venues such as clubs, theaters, and small arenas.
Compare
Discover which power level will best fit your specific application.
RAW 3 FB4
RAW 5 FB4
RAW 10 FB4
Full-colour, Semiconductor diode laser system
Full-colour, Semiconductor diode laser system
full-color, semiconductor diode laser system
>3W
>5W
>10W
Clubs, DJs, medium indoor venues (up to 3,000 people), home and hobby use. Beam show, text, graphic, and mapping capable
Clubs, DJs, large indoor venues (up to 5,000 people), small outdoor shows. Beam show, text, graphic, and mapping capable
Clubs, DJs, large indoor venues (over 5,000 people), medium sized outdoor shows. Beam show, text, graphic, and mapping capable
Pangolin FB4 DMX [Ethernet, ArtNet, DMX, sACN, ILDA out | PC, Lighting Console, Auto Mode, Mobile App: Apple, Android]
Pangolin FB4 DMX [Ethernet, ArtNet, DMX, sACN, ILDA out | PC, Lighting Console, Auto Mode, Mobile App: Apple, Android]
Pangolin FB4 DMX [Ethernet, ArtNet, DMX, sACN, ILDA out | PC, Lighting Console, Auto Mode, Mobile App: Apple, Android]
30,000 points per second @ 8°
30,000 points per second @ 8°
30,000 points per second @ 8°
50°
50°
50°
Fully complies with the latest EN 60825-1 and FDA regulations
Fully complies with the latest EN 60825-1 and FDA regulations
Fully complies with the latest EN 60825-1 and FDA regulations
5.3kg
8kg
12kg
Laser projector w/ FB4 DMX, protective case, Estop box, Estop cable (10M/30ft), ethernet cable (10M/30ft), power cable (1.5M/4.5ft), interlock, keys, manual, quickstart guide, variance card (* service dongle if outside US)
Laser projector w/ FB4 DMX, protective case, Estop box, Estop cable (10M/30ft), ethernet cable (10M/30ft), power cable (1.5M/4.5ft), interlock, keys, manual, quickstart guide, variance card (* service dongle if outside US)
Laser projector w/ FB4 DMX, protective case, Estop box, Estop cable (10M/30ft), ethernet cable (10M/30ft), power cable (1.5M/4.5ft), interlock, keys, manual, quickstart guide, variance card (* service dongle if outside US)
500 | 800 | 1,700
1,200 | 1,000 | 2,800
2,700 | 2,700 | 4,800
638nm | 525nm | 455nm
638nm | 525nm | 455nm
638nm | 525nm | 455nm
5 x 3
5 x 3
5 x 3
<1.1mrad [Full Angle]
<1.1mrad [Full Angle]
<1.1mrad [full angle]
Analog 50kHz
Analog 50kHz
Analog, up to 50kHz
100-230V/50Hz
100-230V/50Hz
100-230V/50Hz
Max. 100W
Max. 150W
max. 350W
10-40 °C
10-40 °C
10-40 °C
IP4X
IP4X
IP4X
All the adjustments, such as power output of each color, X & Y axes invert, X & Y size and position, safety, etc., are managed digitally by the FB4 control system. Ethernet in, power in/out, DMX in/out, Estop in/out, ILDA out.
All the adjustments, such as power output of each color, X & Y axes invert, X & Y size and position, safety, etc., are managed digitally by the FB4 control system. Ethernet in/out, power in/out, DMX in/out, Estop in/out, ILDA out
All the adjustments, such as power output of each color, X & Y axes invert, X & Y size and position, safety, etc., are managed digitally by the FB4 control system. Ethernet in/out, power in/out, DMX in/out, Estop in/out, ILDA out
Keyed interlock, Emission delay, Magnetic interlock, Scan-fail safety, Mechanical shutter, Adjustable aperture masking plate
Keyed interlock, Emission delay, Magnetic interlock, Scan-fail safety, Mechanical shutter, Adjustable aperture masking plate.
Keyed interlock, emission delay, magnetic interlock, scan-fail safety, mechanical shutter, adjustable aperture masking plate.
*Due to the Advanced Optical Correction technology used in our laser systems, each laser colour's optical power output may slightly differ from the specification of the respective laser module(s) installed. This does not affect the total guaranteed power output
*Due to Advanced Optical Correction technology used in our laser systems, each laser colour's optical power output may slightly differ from the specification of the respective laser module(s) installed. This does not affect the total guaranteed power output
*Due to Advanced Optical Correction technology used in our laser systems the optical power output of each laser colour within the system may slightly differ from the specification of respective laser module(s) installed. This does not affect the total guaranteed power output.
Depth: 238 | Width: 192 | Height: 126
Depth: 252 | Width: 247 | Height: 148
Length: 340 | Width: 247 | Height: 148
Control
Unity RAW FB4 lasers come with our FB4 hardware integrated inside. Allowing you to control these lasers from a lighting console, PC, as well as in stand-alone “auto” mode. Additionally, the lasers support all major lighting protocols (DMX, ArtNET, sACN, timecode, and more) so you can easily integrate into any advanced multimedia show workflow. Multiple lasers can also easily be connected (over ethernet, ArtNET, or DMX) so you can run synchronized multi-projector shows easily.
Functionality
The RAW FB4 is a pure diode-based laser projector with a vibrant, balanced white output. Equipped with true analog modulation, it offers smooth fade-in and fade-out transitions for seamless visual effects.
Safety
We equip the RAW FB4 with the very latest in laser safety features (including e-stop and interlock with manual reset, emission delay, mechanical shutter, and masking plate). Convenient external adjustments are also provided natively on the lasers through the FB4 digital display, offering tools to adjust size, position, rotation, colors, geometric correction, and more. Additionally, the lasers feature ethernet in (and out, on 5W and 10W models), power in/out, DMX in/out, Estop in/out, and ILDA out connectivity.
